Right View
Dumping
Multi Uplifting
Left View
The FS80-90-110 models are the most compact sweeping machines in their class. They are designed with a box frame, constructed around a compact central brush. This allows FS80-90-110 to be used for cleaning large surfaces, as well as restricted or cluttered passageways. They are available with central brushes of three different widths: 80, 90 and 110 cm and battery- or diesel-powered (FS80-90-110 D). The FS110 version is also available with a Bifuel gasoline/LPG endothermic engine.
| Productivity theoretical (up to sqm/h) | FS-80 D(12960)/ FS-80 B(11520) |
| Central brush working width (mm) | 800 |
| Working width with side brushes (no.) (mm) | (1) 1120/(2) 1440 |
| Debris hopper volume (l) | 360 |
| Type of loading system | front |
| Type of drainage | hydraulic |
| Filtering surface area (sq.m.) | 7 |
| Supply/traction | diesel engine / hydraulic |
| Machine dimensions (L x h x w) (mm) | 2020 x 1430 x 1130 |
| Machine weight empty without batteries (kg) | FS-80 D(730)/ FS-80 B(750) |
| Productivity theoretical (up to sqm/h) | 12960 |
| Central brush working width (mm) | 800 |
| Working width with side brushes (no.) (mm) | (1) 1120/(2) 1440 |
| Debris hopper volume (l) | 360 |
| Type of loading system | front |
| Type of drainage | hydraulic |
| Filtering surface area (sq.m.) | 7 |
| Supply/traction | diesel engine / hydraulic |
| Machine dimensions (L x h x w) (mm) | 2020 x 1430 x 1130 |
| Machine weight empty without batteries (kg) | 730 |
| Productivity theoretical (up to sqm/h) | 12320 |
| Central brush working width (mm) | 900 |
| Working width with side brushes (no.) (mm) | (1) 1220/(2) 1540 |
| Debris hopper volume (l) | 400 |
| Type of loading system | front |
| Type of drainage | hydraulic |
| Filtering surface area (sq.m.) | 8 |
| Supply/traction | battery 36V / hydraulic |
| Battery run time (up to h) | 4 |
| Machine dimensions (L x h x w) (mm) | 2020 x 1430 x 1230 |
| Machine weight empty without batteries (kg) | 710 |
| Productivity theoretical (up to sqm/h) | 13860 |
| Central brush working width (mm) | 900 |
| Working width with side brushes (no.) (mm) | (1) 1220/(2) 1540 |
| Debris hopper volume (l) | 400 |
| Type of loading system | front |
| Type of drainage | hydraulic |
| Filtering surface area (sq.m.) | 8 |
| Supply/traction | diesel engine / hydraulic |
| Machine dimensions (L x h x w) (mm) | 2020 x 1430 x 1230 |
| Machine weight empty without batteries (kg) | 770 |
| Productivity theoretical (up to sqm/h) | 13920 |
| Central brush working width (mm) | 1100 |
| Working width with side brushes (no.) (mm) | (1) 1420/(2) 1740 |
| Debris hopper volume (l) | 480 |
| Type of loading system | front |
| Type of drainage | hydraulic |
| Filtering surface area (sq.m.) | 8 |
| Supply/traction | battery 36V / hydraulic |
| Battery run time (up to h) | 4 |
| Machine dimensions (L x h x w) (mm) | 2020 x 1430 x 1430 |
| Machine weight empty without batteries (kg) | 750 |
